Integrated Long Range UHF RFID Reader For Automatic Parking Gate Barrier System

  • Integrated Long Range UHF RFID Reader For Automatic Parking Gate Barrier System
  • Integrated Long Range UHF RFID Reader For Automatic Parking Gate Barrier System
Place of Origin China
Brand Name SEWO
Certification CE，IS09001
Model Number SEWO-T91
Document Product Brochure PDF
Minimum Order Quantity 1 lane
Price Negotiable
Packaging Details wooden box
Delivery Time 5-7 working days
Payment Terms T/T, Western Union, MoneyGram, L/C, D/A, D/P
Supply Ability 2000 sets per month

Contact me for free samples and coupons.

WhatsApp:0086 18588475571

wechat: 0086 18588475571

skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Product Name Bluetooth Long-range Card Reader Power Supply DC 12V/3A
Processor 32bit ARM Cortex-M3 Working Frequency 433MHZ
Infrared Frequency 38KHZ Reading Range 60--120°adjustable
Reading Distance 1-15 Meters Adjustable Response Time 0.1 Seconds
Reading Speed 0.2 Seconds Waterproof IP67
Highlight

Integrated Long Range UHF RFID Reader

,

Parking Management Long Range UHF RFID Reader
Leave a Message
Product Description

Integrated Long Range UHF RFID Reader For Automatic Parking Gate Barrier System Parking Management

Discriptions of Long Distance Range Parking System:

    SEWO RFID UHF Long Lange Reader for Parking Lot Management UHF reader is a high performance Multiple Protocol UHF RFID Reader. Based on proprietary efficient digital signal processing algorithm, it supports fast tag read/write the tag and stickers and operation with high identification rate. It can be widely applied in many RFID application systems such as logistics, access control, attendance system, anti-counterfeit and industrial production process control system.



Advantage of SEWO UHF Parking System:

1. Optical excitation, CDMA, sleep/wake up, wireless communications, CPU automatic recognition and so on cutting-edge high-tech crystal
2. Adopt 32bit Cortex-M3 Micro processor
3. High Reading speed, card can be read in 10-40 km/h without vehicle stop
4. Long range reading distance, 3~5 m(adjustable)
5. With good directivity, optical excitation range can be up to 120°
6. Advanced CDMA communication technology is used and no interference
between adjacent lane
7. No need to stop and no need to open the window to read card
8. Reading direction can be adjusted discretionarily
9. Output mode: WG26/WG34/RS485/RS232,



Specifications of Small UHF Bluetooth Parking System:



Product Name SEWO-T9103
Dimension 215 * 225 * 52mm
Power Supply DC 12V/3A
Working mode read-only type
Operating frequency 902~928MHz (FCC part 15)/865.6~867.5MHz (EU)/920~925 MHz (China)
Support tag protocol EPC C1 GEN2
Communication speed up to 115200bps
Communication interface wiegand26/34, RS232, RS485, LAN (RJ45, TCP/IP)
Recognition distance greater than 3-5 meters
Working temperature -20 ℃~+70 ℃
Storage temperature -40 ℃~+85 ℃



Features:
  1. Reading Distance: 3~5 meters
  2. In hand or vehicle-mounted auto reading, dual reading mode
  3. Access control cards can be affixed to the back of the card for “One-Card System”
  4. Passwords, license plates and other coded information can be stored
  5. Battery: CR3240 button cell
  6. Battery Life: 505,000 (handheld)
  7. Working Mode: read-write in real time (with CDMA module)

Integrated Long Range UHF RFID Reader For Automatic Parking Gate Barrier System 0
